Note: Picture of the box is for illustration purposes only, the design of the packaging may change over time and is not always representive of the leads in the kit. Some lead kits will be made up from loose leads from our stock, and will not come in a box or packaging.

“

STAINLESS STEEL FERRITE SPIRAL CORE
Ignition leads are the top of our range for street driven vehicles!
Lead Diameter8mm
ColourBlue, Black & Red
ApplicationPassenger, Performance, Commercial & 4WD vehicles including Super & Turbo charged motors.
DescriptionEliminator Series 1 ignition leads are the top of our range for street vehicles. They withstand high heat and are fitted with our 1300 ohms per metre Ferrite Spiral Core conductor which by induction design delivers peak voltage to the plugs ensuring complete combustion for super quick starts and smooth running.
Cable Standards

Tested to ISO 3808 Standards.

FeaturesEagle's Finger Grip SPB Features*
  • Eagles computer designed “finger grip” Spark Plug Boot allows easy on – easy off installation.
  • Unequaled durability by using our best High Temp Silicone compounds.
Terminal Features
  • Zero rust 0.43mm Stainless Steel base.
  • High Memory spring steel retaining clip for positive terminal locking at all RPM'S.
  • Triple cable retaining ribs and “W” shaped crimp ensure superior cable retention.
Distributor Boot Features
  • High Dielectric strength EPDM.
Cable Features
  • The heart and soul of our Eliminator Series lead. Stainless Steel wound Ferrite Spiral Core conductor with super low resistance for maximum voltage delivery.
  • High Dielectric Silicone inner jacket.
  • Technologically advanced nylon tape adds tensile strength.
  • 260°C high-temp Silicone outer and inner jackets.
Please NoteAbove specifications may vary due to technological advances at manufacturer’s discretion.
WarningThe product description above is to be used as a guide only. It is up to the purchaser/end user to determine the correct suitability/application of product to suit their individual requirements. Care must be taken when selecting product. For Warranty information on above Leads, refer to back cover.
* Not required on certain vehicles.
SKU E86780-ITR5H13
Barcode # 9331678066465
Brand Eagle & NGK
Assembled Length 0.010m
Assembled Height 0.010m
Lead Colour Black
Lead Thickness 8mm
Leads In Kit 6
Universal Fitment No
Select your vehicle using the Part Finder to check fitment for your specific vehicle.
