Eagle Blue 10.5mm Eliminator Ignition Leads Set E1056194
SKU: E1056194
Eagle 10.5mm Eliminator Series Ignition Leads — Blue
The Eagle Eliminator Series 10.5mm ignition leads represent the next generation in high-performance and racing ignition lead technology, as used by major race teams worldwide.
- 10.5mm diameter leads in Blue
- Ultra-low 325 ohms per metre resistance — spiral wound Copper over Ferrite-coated Kevlar® inner core
- Three layers of 260°C Hi-temp Silicone jackets for superior insulating properties, capable of carrying secondary voltages in excess of 70,000 volts
- Emits virtually zero RFI — compatible with virtually all hi-tech on-board computer systems
- Nylon Tape layer provides exceptional tensile and terminal pull-off strength
- Finger Grip Spark Plug Boot Design for easy fitment and removal
- Computer Aided Boot Design replicates the terminal's shape, eliminating any chance of crossfire
- High memory spring steel retaining clip designed for positive terminal locking at all RPM
- Zero-rust 0.43mm stainless steel base terminals with triple cable retaining ribs and "W" shaped crimp for superior cable retention
- Designed for all ignition systems including very high output aftermarket systems (e.g. Crane® and MSD® types — consult your ignition manufacturer for compatibility)
- Tested to ISO 3808 Standards
- Available in Blue, Red or Black — custom leads available by request
- Made in Australia
From V8 Supercars to street cars, world-class rally, touring cars, power boat racing and top fuel dragsters — Eagle ignition leads are trusted by professional race drivers and everyday motorists alike. Specifications may vary due to technological advances at the manufacturer's discretion. It is the responsibility of the purchaser to confirm correct suitability and application for their individual requirements. Kevlar® is a registered trademark of DuPont™.
Specifications
| Lead Diameter | 10.5mm |
|---|---|
| Colour | Blue |
| Application | High Performance Street /Strip vehicles but primarily designed for racing applications burning Hi-octane and Methanol fuels. |
| Ignition System Compatibility | Very high output aftermarket ignition systems including most Craneª & MSDª types. Note: We recommend consulting with your ignition manufacturer for system compatibility before using this product. |
| Description | Eliminator Series II ignition leads have been specifically designed to cope with todayÕs high compression high horsepower race engines. Being fitted with three layers of Silicone jackets, they are a proven performer at carrying secondary voltages in excess of 70,000 volts whilst emitting virtually zero RFI making them compatable for use with virtually all hi-tech on board computer systems. |
| Cable Standards | Tested to ISO 3808 Standards. |
| Features | Eagle's Finger Grip SPB Features Eagles computer designed “finger grip” Spark Plug Boot allows easy on Ð easy off installation. Unequalled durability by using our best High Temp Silicone compounds. Terminal Features Zero rust 0.43mm Stainless Steel Base. High Memory spring steel retaining clip for positive terminal locking at all RPM'S. Triple cable retaining ribs and “W” shaped crimp ensure superior cable retention. Cable Features Ultra low 325 ohms per metre resistance Spiral wound. Stain Steel over Ferrite coated Kevlarª inner core. Nylon Tape gives exceptional tensile and terminal pull off strength. Three 260¡ C Hi-temp Silicone jackets for superior insulating properties. |
| Please Note | Above specifications may vary due to technological advances at manufacturerÕs discretion. |
| Warning | The product description above is to be used as a guide only. It is up to the purchaser/end user to determine the correct suitability/application of product to suit their individual requirements. Care must be taken when selecting product. For Warranty information on above Leadss, refer to back cover. |
| SKU | E1056194 |
| Model # | E1056194 |
| Barcode # | 9331678028203 |
| Brand | Eagle |
| Assembled Length | 0.010m |
| Assembled Height | 0.010m |
| Placement On Vehicle | Engine |
| Lead Colour | Blue |
| Lead Thickness | 10.5mm |
| Leads In Kit | 7 |
| Manufacturer Part Number | E1056194 |
| Position On Vehicle | Engine |
| Contains Liquid | No |
Eagle Products is the largest privately owned ignition lead manufacturing company in Australia. Established in 1984.
Eagle has invested heavily in world leading state of the art equipment that puts them in a commanding position to take advantage of future growth, One of their main secrets to quality is that each and every Ignition Lead processed by Eagle Products is individually tested for correct resistance to ensure product performance time after time.
In the pursuit of excellence, Eagle Products utilise Australia's finest race cars and their state of the art engine dyno facilities as product test beds to enable them to produc the very best Ignition Leads possible for today's high technology motor vehicles.
- Manufacturered in Australia from imports components.
- Australian owned and private company
- Eagle leads are used on many of the V8 Supercars and Drag cars in Australia
